Sentrameter

Brand: RIKEN KEIKI

Portable HC/O2 Gas Detector

Application

· Oil tanker

· Gas carier

· Product tanker

· Refineries/Petrochemical/Chemical plants

· Confined space

· Gas plant/Gas supplier services

· Power plant

· Water/Wastewater Treatment

· Utilities

Features

· Real-time detection for combustibles 100%LEL / 100%VOL, O2

· Large simultanenous display with auto back lighting

· Strong sample drawing capablity

· Loud alarm buzzer with 95dB

· 3 Brights LED alarm Windows

· ATEX Exia II CT4 / MED

· Water and dust resistent IP67

· Lithium-ion rechargeable battery

· Compact and light weight

· Ergonomic design with waist strap for hands free operation

· Dataloging standard

RIKEN KEIKI RX-8000
SPECIFICATIONS
Target gas	Combustibles		Oxygen
	(i-C₄H₁₀ or CH₄ calibration)		(O2)
Detection principle	Non-Dispersive Infrared Ray		Galvanic cell
Detection Range ( Increments)	0-100vol%	0-100%LEL	0-40%
	(0.5vol%)	(0.5%LEL)	(0.1%)
Accuracy	±5vol%	±5%LEL	Range 0-25% : ±0.7%
			Range 26-40% : ±3.0%
Response time	T90 within 30sec		T90 within 20sec
Sampling method	Sample draw : Minimum 0.75L/min
Display	Digital display and Bar graph
Power source	Lithium-ion battery ( hours for a full charge) : Standard
	AA Alkaline battery ( 3Pcs ) : Option
Continuous Operation	Lithium-ion battery : more than 15 hours
	AA Alkaline battery : more than 10 hours
Operating temp & Humidity	−20 + 50°C (-4 + 122°F ) below 95%Rh (Non-condensing)

Dimensions & Weight	Approx. 154(W) x 81(H) x 127(D)mm Approx. 1.0Kg
	(Approx. 6.1"(W) x 3.1"(H) x 5.0"(D)mm Approx. 2.4lb)
Ingress proof rating	IP67
Explosion proof	Ex ia IIC T4 Ga
Approvals	IECEx, ATEX, MED
	Complying to IEC60079-29-1, EN50104
Additional features	Indication to show energizing (pilot indicator and pump driving indicator), Activating cofirmation
	beep and LED's flash (every one minute), Pump stop function, Bump test function,
	irDA coatmmunication, Data logger, Paswword protection
