Penjelasan Produk :

High transfer efficiency Heavy duty Excellent handling

Features

High transfer efficiency Heavy duty Excellent handling

●Realizing high quality paint film by optimum spraying paint volume.

●Stable air flow vastly realizes the prevention of air pressure lost.

●Reduction of paint consumption, and small air consumption in saving energy.

●Optimum air flow brings the reduction of paint adhesion to air cap set.

●Easy handling with optimum weight balance and light weight.

●Reduction of trigger load, and improvement of usability with lower resistance packing.

●Waterborne compatibility.

●Improvement of parts durability.

●Addition of Semi-tulip pattern.

●Each nozzle bore size has its own air cap set.

●Air cap sets for suction, gravity, and pressure type are interchangeable in the same fluid nozzle bore size

Specification :

Model No.		F210-P12P	F210-P15P	F210-P20P	F210-P25P	F210B-P30P
Paint feed system		Pressure
Nozzle Bore	mm	1.2	1.5	2.0	2.5	3.0
Standard air cap		12P	15P	20P	25P	30P
Spraying Pressure	MPa	0.25
Spraying sidtance	mm	250
Air con-sumption	L/min	335	345	375	410	420
Paint spraying volume	mL/min	530	880	1280	1710	1940
Maximum effective	mm	350	370	400	420	440
pattern width
Pattern Shape		Tulip
Required compressor output	kW	2.2 or more			3.7 or more
Weight	g	391
Standard paint cup		Paint pressure feed tanks, diaphragm paint pumps
Measurement	m3	0.06/25PC
