YAMADA AODD POMPA NDP 25 BSN

Brand: YAMADA

Penjelasan Produk :

Intake & discharge connection:polypropylene(PPG )1"Female NPTKynar*(PVDF)1"FemaleNPAluminum(ADC-12) 1"Female NPT

Port Dimensions (462 GPM Max.)    Intake & discharge connection: polypropylene (PPG ) 1"Female NPT Kynar* (PVDF) 1"Female NPT Aluminum(ADC-12) 1"Female NPT Stainless Steel (ADC-12) 1"Female NPT Cast Iron 1"Female NPT Air inlet (incl.ball valve): 3/8" Female NPT Air exhaust (incl.ball silencer) 3/4 Female NPT ANSI Flange also available - consult Yamanda.
Maximum Liquid Temperature* Diaphragm Material Temperature Buna N 180°F (82°C) Neoprene 180°F (82°C) Santoprene* (TPO) 180°F (82°C) EPDM 212°F (100°C)    PTFE 212°F (100°C) Hytrel* (TPEE) 248°F (120°C)    Viton* fluoroelastomer 248°F (120°C) *The maximum liquid temperature for metal and Kynar*-fit-ted pumps is determined by the elastomer (diaphragm material).
Poly propylene pumps have a maximum liquid temperature of 180°C) regardless of diaphragm mate-rial.Air supply Pressure(All Models)20- 100 PSI (1.4-7 kfg/cm)Discharge volume Per Cycle Rubber diaphragm: 0.22 gallons 833 cc)PTFE diaphragm: 021 gallons (787 cc)Maximum Cycles Per Minute Rubber diaphragm: 210 PTFE diaphragm:210 Maximum Size Solid 3/16"(4.8 mm)
Maximum Dry Suction lift Rubber-fitted pump capability: 18-feet Air Motors: Aluminum air motors are standard on metal pumps;glass-filled polypropylene air motors are standard on plastic and Kynar* pumps.Optional: Split manifold --contact Yamada Notes: Santoprene*fitted pumps include EPDM wetted o-rings.           Kynar*(PVDF) pumps fitted with santoprene*, Hytrel*, or PTFE include PTFE check balls & 0-rings.Kynar*/EPDM fitted pumps include EPDM check balls & o-rings.Viton*/fitted pumps include Viton*balls & o-rings.

Aluminum
Dimensions: 11.30" W X 15.08"H
Net Wt.: 27 lbs.(13.0 kg)
Shipping Wt.: 31 lbs.
Kynar* (PVDF)
ANSI Flange Dimensions:    14.40" W x 17.40 " H
NPT Dimensions:
14.40" W x 16.90"H
Net Wt.: 29.7 lbs . (13.4 kg)
Shipping Wt.: 33 lbs.

Polypropylene
ANSI Flange Dimensions: 14.40''W x 17.40 " H
NPT Dimensions : 14.40" W x 16.90"H
Net Wt.: 2 lbs.(10.9 kg)
Shipping Wt.: 30 lbs.
Cast Iron or S.S.
Dimensions:11.30" W x 15.08"H
Net Wt.: 43 lbs.(19.9 kg)
Ship Wt.: 46 lbs.
