• Electromagnetic spring-applied failsafe brake

• Heavy duty high efficiency ball bearing on all running surfaces

• Planetary gears for maximum mechanical efficiency

• Cast steel foot mountings

• Fabricated steel drum

• Supplied on steel base plate ready to mount

• Rated capacity limiter limits driving power of the motor to prevent overloading of the winch

• Quiet running

• Low voltage control ass'y comes as standard

• Emergency stop function switch is available upon request.

Specifications

• Lifting capacity: 2,200 kg at wire rope top layer

• Lifting speed:

Option A: 6.9 - 12.6 m/min

Option B: 4.5 - 8.3 m/min

• Power source: 3 phase, 380-440V

• Motor rating IP54:

Option A: 5.5 kW x 4 poler induction motor

Option B: 3.8 kW x 6 poler industion motor

• Gear ratio: 127:1

• Maximum lifting height: 97 m

• Braking methods: Electromagnetic

• Wire rope: 16 mm x 100 m

• Drum length: 312 mm

• Drum dia: 178 mm

• Drum flange dia: 410 mm

• Mounting bolt pattern: 600 mm x 499 mm
