*Tipe HZ adalah tipe dengan 6 baut pada cylinder head.HZ type is a 6 bolt cylinder head type.
*Tipe HDTT adalah tipe tanpa menggunakan tangki hopper dan tangki solar. HDTT type is a tipe with no hopper tank and diesel fuel tank.
*Sistem pembakaran langsung dapat menghemat solar sampai dengan 20% fuel consumption comparing to convensional (tak langsung).Direct injection combustion system saves up to 20% fuel tank.
*Spesifikasi dan dimesin dapat berubah tanpa pemberitahuan terlebih dahulu.Specifications are subject to change without prior notice.

Tipe: Mendatar, 4 langka pengin udara, horizontal, 4 cycle, air cooling
jumlah silinder Number of cylinder: Mendatar, 4 langkah, pendingin air, water cooling
Diameter langkah bore x stroke (mm) (mm): 75 x 75
Isi silinder displacement (cc) (cc): 331
Sistem pembakaran combustion system: Tak langsung / indirect
Tenaga maksimum max power (HP/rpm) (HP/rpm): 6.5 / 2600
Tenaga kontinyu Continuous power (HP/rpm) (HP/rpm): 5.5 /2600
Perbandingan kompresi Compression ratio: 20.5: 1
Sistem pendinginan Cooling system : Pendinginan udara / air cooling
Sistem governom Governor system: Mekanis / mechanical
Sistem pengasutan Starting system: Engkol / hand starting
Arah putaran Rotation Berlawanan arah jarum jam, dilihat dari sisi roda penerus / counter clockwise, viewed from flywheel side
Kapasitas oli Oil capacity (L) (L): 1.2
Berat bersih Weight (kg) (kgs):49
